PowerShield PSVR6 Wall Mount Rack — 6U Vertical UPS
SRTL1500RMXLI-NC is a 1500VA/1350W double conversion online UPS designed for enterprise networking infrastructure. Features advanced Li-ion battery technology, 8x IEC C13 outlets, 3U rackmount design, and includes network management card for remote monitoring and control.
Original price was: $7,400.00.$6,358.50Current price is: $6,358.50. inc GST.
BUZY's take on this product:The APC Smart-UPS SRTL1500RMXLI-NC delivers enterprise-grade power protection in a compact 3U rackmount form factor, making it an ideal solution for protecting critical networking infrastructure including UniFi controllers, switches, and security appliances. This double conversion online UPS provides continuous 1500VA/1350W of clean, regulated power with less than 2% output voltage distortion, ensuring your networking equipment receives stable electricity regardless of utility power fluctuations or outages.
The true online double-conversion topology delivers pure sine wave output with zero transfer time during power events, eliminating the micro-interruptions that can disrupt sensitive networking equipment. With its included network management card and Smart-Slot for future expansion, this UPS integrates seamlessly into professional IT environments, providing the reliable power protection that UniFi deployments and critical network infrastructure demand. The included rail kit ensures straightforward rack installation alongside your networking equipment.
Output
Output Power Capacity
1350 Watts / 1500 VA
Max Configurable Power (Watts)
1350 Watts / 1500 VA
Nominal Output Voltage
230V
Output Voltage Distortion
Less than 2%
Output Frequency (sync to mains)
50/60Hz +/- 3 Hz
Other Output Voltages
220, 240V
Crest Factor
3 : 1
Double Conversion Online
Waveform Type
Sine wave
Output Connections
(8) IEC 320 C13 (Battery Backup)
Bypass
Built-in Bypass
Input
Nominal Input Voltage
230V
Input Frequency
40 – 70 Hz (auto sensing)
Input Connections
IEC-320 C14
Input voltage range for main operations
50-150 (40% Load) V , 80 – 150 V
Other Input Voltages
220 , 240
Batteries Runtime
Battery Type
Li-ion
Typical recharge time
6 hour(s)
Nominal Battery Voltage
48V
Communications Management
Interface Port(s)
RJ-45 Serial , Smart-Slot , USB
Available SmartSlot™ Interface Quantity
1
Control panel
Multi-function LCD status and control console
Audible Alarm
Audible and visible alarms prioritized by severity
Emergency Power Off (EPO)
Yes
Surge Protection and Filtering
Surge energy rating
340 Joules
Physical
Maximum Height
128.0 mm
Maximum Width
432.0 mm
Maximum Depth
590.0 mm
Rack Height
3 U
Net Weight
30.53 kg
Shipping Weight
46.86 kg
Shipping Height
445.0 mm
Shipping Width
600.0 mm
Shipping Depth
850.0 mm
Color
Black
Units per Pallet
6.0
Environmental
Operating Environment
0 – 40 °C
Operating Relative Humidity
0 – 95 (non-condensing) %
Operating Elevation
0-3000 meters
Storage Temperature
-15 – 45 °C
Storage Relative Humidity
0 – 95 (non-condensing) %
Storage Elevation
0-15000 meters
Audible noise at 1 meter from surface of unit
50.000 dB
Online Thermal Dissipation
450.000 BTU/hr
Protection Class
IP 20
Conformance
Approvals
CE , CE Mark , EAC , RCM , VDE
Standard warranty
5 year repair or replace
Sustainable Offer Status
RoHS
Compliant
REACH
REACH: Contains No SVHCs
Battery Directive
C
| Weight | 43 kg |
|---|---|
| Shipping Dimensions | 59.4 × 63 × 28.6 cm |
| Brand | |
| Manufacturer Part# | SRTL1500RMXLI-NC |
| Warranty (months) | 24 |
| More info (manufacturer's website) | |
| Condition | New |
